NNC69C Mini Electromagnetic Relay
Request a Quote
The NNC69C mini electromagnetic relay can be applied to household appliances, PCB circuit board, industrial control system and automatic control system, etc.
Features
- The NNC69C mini electromagnetic relay provides changeover contacts that include one group of (16A).
- The device can directly welded on the printed circuit board.
Identification
CCC: 2011010303471250
CE: 5400090516
CQC: CQC17002174758
UL: E235027
Model explanation
Contact parameters
| Contact form | 1H |
| Contact load | 16A |
| Maximum switching voltage | 240VAC 16A 28VDC 16A |
| Contact material | Silver alloy |
Relay coil
| Rated voltage V | DC12V | DC24V | DC48V | DC110V |
| Rated current (±10%) mA | 44 | 22 | 11 | 4.8 |
| Coil resistance (±10%) Ω | 272 | 1090 | 4363 | 22916 |
| Rated power consumption W | 0.53W | |||
| Pull-in voltage (Maximum) V | Below 75% | |||
| Drop-out voltage(Minimum) V | Above 10% | |||
| Allowable voltage(Maximum) V | Rated voltage×110% | |||
Specification of NNC69C mini electromagnetic relay
| Coil voltage | DC:3 - 110V | |
| Pull-in time | ≤20ms | |
| Drop-out time | ≤10ms | |
| Withstand voltage | Between the homopolar contacts | 1200VAC/1min(Leakage current 1mA) |
| Between the heteropolar contacts | / | |
| Between contacts and coil | 5000VAC/1min(Leakage current 1mA) | |
| Dimension | 29 × 12.5 ×24mm | |
| Weight | About17g | |
Dimension and installation
① Front view; ② Side view; ③ Installation size; ④ Wiring diagram
