WN202RA100M Dual-Axis Motorized Rotation Stages
WN202RA100M dual-axis motorized rotation stage can rotate 360°around Y, Z axes. Equipped with stepper motor and high precision worm gear system, the rotation stage can rotate forward and backward at ease with minimal backlash.
Weight: 4.4kg; center load capacity: 8kg; Worm gear ratio: 180∶1; speed: 10°/sec.
| Model | WN202RA100M | |
| Structure | Angle range | 360°Rotation around Y,Z axes |
| Worm gear ratio | 180∶1 | |
| Driving gear | Electric rotary table | |
| Guide rail | Bearing | |
| Stepper motor (1.8°) | SST42D3301 | |
| Material | Aluminum alloy | |
| Surface | Blackened by anodic oxidation | |
| Center load capacity | 8kg | |
| Weight | 4.4kg | |
| Accuracy | Resolution | 0.01°=36″(Non-MS driver) 0.0005°=1.8″(20 MS driver) |
| Speed | 10°/sec | |
| Repeatability | 0.01°=36″ | |
| Main module：WN02RA100M | ||
