WN303RA200S Multi-Axis Motorized Rotation Staged
Featured with high precision worm gear structure, WN303RA200S multi-axis motorized rotation stage has high center load capacity and a long lifespan. It can rotate 360°forward and backward around X, Y, Z axes with minimal backlash. The stage weighs 36kg with the center load capacity of 25kg, worm gear ratio is 180∶1, the rotating speed is 10°/sec.
| Model | WN303RA200S | |
| Structure | Angle range | 360°Rotation around X, Y, Z axes |
| Worm gear ratio | 180∶1 | |
| Driving gear | Electric rotary table | |
| Guide rail | Bearing | |
| Stepper motor(1.8°) | SST57D3301 | |
| Material | Aluminum alloy | |
| Surface | Blackened by anodic oxidation | |
| Center load capacity | 25kg | |
| Weight | 36kg | |
| Accuracy | Resolution | 0.01°=36″(Non-MS driver) 0.0005°=1.8″(20 MS driver) |
| Speed | 10°/sec | |
| Repeatability | 0.01°=36″ | |
| Main module：WN03RA200S | ||
