JAC-S998SX Ceramic Alumina Flap Discs Manufacturer

JAC-S998SX Ceramic Alumina Flap Discs

: http://indus-abrasives.com/1-1-3-4-ceramic-alumina-flap-discs.html

Availability

Product Code	JAC-S998SX	JAC-S998SX	JAC-S998SX
Abrasive Grains	Premium Ceramic Alumina	Premium Ceramic Alumina	Premium Ceramic Alumina
Flap Disc Density	Standard	Standard	Standard
Flap Fitted Versions	Single / Double	Single / Double	Single / Double
Backing Plate Material	Reinforced Fiberglass	Reinforced Nylon	Turbo-Cooling Trim Plastic
Flap Disc Shape Available	T29-Conical / T28-Convex / T27-Flat	T29-Conical / T28-Convex / T27-Flat	T29-Conical / T27-Flat

BRITSH SIZE	METRIC SIZE	GRIT	MAX	STD	PART #			PART #			PART #
( D x H )	( D x H )	GRIT	RPM	PACK	T27	T28	T29	T27	T28	T29	T27	T28	T29
4" x 5/8"	100 mm x 16 mm	36	15,300	10	90007	91565	90008	90736	91878	90737
		40			90010	91578	90011	90749	91881	90840
		50			90023	91581	90024	90852	91894	90853
		60			90036	91594	90037	90865	91907	90866
		80			90049	91607	90040	90878	91910	90879
		100			90052	91710	90053	90881	91923	90882
		120			90065	91723	90066	90894	91936	90895
4-1/2" x 7/8"	115 mm x 22.23 mm	36	13,300	10	90078	91736	90079	90907	91949	90908	91110		91111
		40			90081	91749	90082	90910	91952	90911	91123		91124
		50			90094	91752	90095	90923	91965	90924	91136		91137
		60			90107	91765	90108	90936	91978	90937	91149		91140
		80			90110	91778	90111	90949	91981	90940	91152		91153
		100			90123	91781	90124	90952	91994	90953	91165		91166
		120			90136	91794	90137	90965	92007	90966	91178		91179
5" x 7/8"	125 mm x 22.23 mm	36	12,200	10	90149	91807	90140	90978	92010	90979	91281		91282
		40			90152	91810	90153	90981	92023	90982	91294		91295
		50			90165	91823	90166	90994	92036	90995	91307		91308
		60			90178	91836	90179	91007	92049	91008	91310		91311
		80			90181	91849	90182	91010	92152	91011	91323		91324
		100			90194	91852	90195	91023	92165	91024	91336		91337
		120			90207	91865	90208	91036	92178	91037	91349		91340
6" x 7/8"	150 mm x 22.23 mm	36	10,200	10	90210		90211
		40			90223		90224
		50			90236		90237
		60			90249		90240
		80			90252		90253
		100			90265		90266
		120			90278		90279
7" x 7/8"	180 mm x 22.23 mm	36	8,600	10	90281		90282	91049		91040	91352		91353
		40			90294		90295	91052		91053	91365		91366
		50			90307		90308	91065		91066	91378		91379
		60			90410		90411	91078		91079	91381		91382
		80			90423		90424	91081		91082	91394		91395
		100			90436		90437	91094		91095	91407		91408
		120			90449		90440	91107		91108	91410		91411
4-1/2" x 5/8"-11	115 mm x M14-2	36	13,300	5	90452		90453				91423		91424
		40			90465		90466				91436		91437
		50			90478		90479				91449		91440
		60			90481		90482				91452		91453
		80			90494		90495				91465		91466
		100			90507		90508				91478		91479
		120			90510		90511				91481		91482
5" x 5/8"-11	125 mm x M14-2	36	12,200	5	90523		90524				91494		91495
		40			90536		90537				91507		91508
		50			90549		90540				91510		91511
		60			90552		90553				91523		91524
		80			90565		90566				91536		91537
		100			90578		90579				91549		91540
		120			90581		90582				91552		91553
6" x 5/8"-11	150 mm x 5/8"-11	36	10,200	5	90594		90595
		40			90607		90608
		50			90610		90611
		60			90623		90624
		80			90636		90637
		100			90649		90640
		120			90652		90653
7" x 5/8"-11	180 mm x 5/8"-11	36	8,600	5	90665		90666
		40			90678		90679
		50			90681		90682
		60			90694		90695
		80			90707		90708
		100			90710		90711
		120			90723		90724
