1200×600mm Single Head CO2 Laser Cutter, CMA1206-B-A Laser Cutting System
Applicable Materials
1200x600mm Single head CO2 laser cutter is designed for cutting wooden products, paper, leather, cloth, polymethyl methacrylate, epoxy resin, acrylic, woolens, plastics, rubber, bamboo ware, garment materials, leather products, mobile phone accessories, adhesive decals, rhinestone, plastic nozzle, jade and other non-metallic materials.
Cutting System
| Model | Version | Laser Power (W) | Laser Head | Wokring Area (mm) | Overall Dimension (mm) | Weight (Kg) | Repeated Positioning Accuracy (mm) | Speed (m/min) | Supply Voltage | Working Environment |
| CMA1206-B-A | HoLi | 60~130 | Single | 1200 × 600 | 1910 × 1380 × 1100 | 430 | ±0.1 | 0~30 | AC 220~240V, 50/60Hz | Temperature: 5-40℃; Humidity: 5-80%. No condensation, no dust or less dust. |
Laser Processing Examples:
- Plush toy laser cutting
- Plush,cloth and shoes laser cutting
- Advertising word laser cutting
- Furry collar laser cutting
- Crystal characters laser cutting
- Fabrics leather suitcase laser cutting
Product Feature
1. The laser cutter body is integrated with various auxiliary equipment’s power supply. The machine’s back is designed with a large cabinet for storing auxiliary equipment.
2. Independently researched and developed, our SmartCarve software can realize high-speed and stable running for precision laser cutting.
3. No. CMA1206-B-A laser cutting system supports 10/100 M Internet and USB 2.0 transmission.
4. This laser cutter supports the display of dynamic process path and coordinate points, with real-time display of processing progress.
5. This laser cutter supports engraving recovery after power off, as well as a working time preview within extreme precision.
6. Optional large format camera and projector positioning function
