WN264TA25H Precision Motorized Linear Stages
WN264TA25H Precision Motorized Linear Stages is suitable for providing linear displacement by electric control in automatic displacement control in scientific research, full-automatic measuring and testing equipment, industrial automation and other fields.
Parameter table of WN264TA25H Precision Motorized Linear Stages| Model | WN264TA25H |
| Travel | 25mm |
| Resolution | 0.125μm |
| Repeatability | 1μm |
| Straightness | 2μm |
| Driving Parallelism | 5μm |
| Pitching (θy) | 10″ (50μrad) |
| Yawing (θz) | 10″ (50μrad) |
| Maximum Speed | 5mm/sec |
| Load Capacity | 10kg |
| Weight | 1.5kg |
- Use high MS stepper motor drive, and the resolution could up to 0.125μm.
- The first choice for precision adjustment. Small size, and use high precision ultra-thin linear guide to ensure high accuracy.
