JAC-C818LX Silicon Carbide Flap Discs Manufacturer

JAC-C818LX Silicon Carbide Flap Discs

: http://indus-abrasives.com/1-1-4-1-silicon-carbide-flap-discs.html

Availability

Product Code	JAC-C818LX	JAC-C818LX	JAC-C818LX
Abrasive Grains	Black Silicon Carbide	Black Silicon Carbide	Black Silicon Carbide
Flap Disc Density	Standard	Standard	Standard
Flap Fitted Versions	Single / Double	Single / Double	Single / Double
Backing Plate Material	Reinforced Fiberglass	Reinforced Nylon	Turbo-Cooling Trim Plastic
Flap Disc Shape Available	T29-Conical / T28-Convex / T27-Flat	T29-Conical / T28-Convex / T27-Flat	T29-Conical / T27-Flat

BRITSH SIZE	METRIC SIZE	GRIT	MAX	STD	PART #			PART #			PART #
( D x H )	( D x H )	GRIT	RPM	PACK	T27	T28	T29	T27	T28	T29	T27	T28	T29
4" x 5/8"	100 mm x 16 mm	36	15,300	10	81001	82569	81002	81730	82872	81731
		40			81014	82572	81015	81743	82885	81744
		50			81027	82585	81028	81756	82898	81757
		60			81030	82598	81031	81769	82901	81860
		80			81043	82601	81044	81872	82914	81873
		100			81056	82614	81057	81885	82927	81886
		120			81069	82627	81060	81898	82930	81899
4-1/2" x 7/8"	115 mm x 22.23 mm	36	13,300	10	81072	82730	81073	81901	82943	81902	82114		82115
		40			81085	82743	81086	81914	82956	81915	82127		82128
		50			81098	82756	81099	81927	82969	81928	82130		82131
		60			81101	82769	81102	81930	82972	81931	82143		82144
		80			81114	82772	81115	81943	82985	81944	82156		82157
		100			81127	82785	81128	81956	82998	81957	82169		82160
		120			81130	82798	81131	81969	83001	81960	82172		82173
5" x 7/8"	125 mm x 22.23 mm	36	12,200	10	81143	82801	81144	81972	83014	81973	82185		82186
		40			81156	82814	81157	81985	83027	81986	82198		82199
		50			81169	82827	81160	81998	83030	81999	82301		82302
		60			81172	82830	81173	82001	83043	82002	82314		82315
		80			81185	82843	81186	82014	83056	82015	82327		82328
		100			81198	82856	81199	82027	83069	82028	82330		82331
		120			81201	82869	81202	82030	83172	82031	82343		82344
6" x 7/8"	150 mm x 22.23 mm	36	10,200	10	81214		81215
		40			81227		81228
		50			81230		81231
		60			81243		81244
		80			81256		81257
		100			81269		81260
		120			81272		81273
7" x 7/8"	180 mm x 22.23 mm	36	8,600	10	81285		81286	82043		82044	82356		82357
		40			81298		81299	82056		82057	82369		82360
		50			81301		81302	82069		82060	82372		82373
		60			81314		81315	82072		82073	82385		82386
		80			81327		81328	82085		82086	82398		82399
		100			81430		81431	82098		82099	82401		82402
		120			81443		81444	82101		82102	82414		82415
4-1/2" x 5/8"-11	115 mm x M14-2	36	13,300	5	81456		81457				82427		82428
		40			81469		81460				82430		82431
		50			81472		81473				82443		82444
		60			81485		81486				82456		82457
		80			81498		81499				82469		82460
		100			81501		81502				82472		82473
		120			81514		81515				82485		82486
5" x 5/8"-11	125 mm x M14-2	36	12,200	5	81527		81528				82498		82499
		40			81530		81531				82501		82502
		50			81543		81544				82514		82515
		60			81556		81557				82527		82528
		80			81569		81560				82530		82531
		100			81572		81573				82543		82544
		120			81585		81586				82556		82557
6" x 5/8"-11	150 mm x 5/8"-11	36	10,200	5	81598		81599
		40			81601		81602
		50			81614		81615
		60			81627		81628
		80			81630		81631
		100			81643		81644
		120			81656		81657
7" x 5/8"-11	180 mm x 5/8"-11	36	8,600	5	81669		81660
		40			81672		81673
		50			81685		81686
		60			81698		81699
		80			81701		81702
		100			81714		81715
		120			81727		81728
