EMA01 2 Flute Square Carbide End Mills

EMA01 2 Flute Square Carbide End Mills
EMA01 2 Flute Square Carbide End Mills
EMA01 2 Flute Square Carbide End Mills
EMA01 2 Flute Square Carbide End Mills
: http://metalworking-tool.com/1-1-ema01-carbide-end-mills-square-2-flutes.html
Feature
  • Specially designed to cut prehardened steel, carbon steel, alloy steel up to HRC56
  • Also suitable for machining stainless steel, titanium, inconel, and other high temperature alloys
  • Excellent for mold & die industry
  • Ideal for high speed cutting, dry and wet cut
  • Oerlikon Balzers coating offers superior hardness and heat resistance
  • Center & slotting cutting
Application
Product Specifications
Coating AITiN /TiALN /TiAISiN
AITiSiN 		HRC HRC46/56
Helix Angle 35°/36°/37° Shank Cylindrical H6
Material IMC™ Carbide Rod Tolerance on Cutting Diameter 0-0.030
Carbide End Mill, Square, 2 Flutes (UNT-EMA01)
UNT EDP # Click to Order Mill Dia
D1 		Shank Dia
D2 		Flute length
L1 		O.A.L
L2 		Flutes
EMA010103 1.0 3 3 50 2
EMA010153 1.5 3 4 50 2
EMA010203 2.0 3 6 50 2
EMA010253 2.5 3 6 50 2
EMA010303 3.0 3 8 50 2
EMA010104 1.0 4 3 50 2
EMA010154 1.5 4 4 50 2
EMA010204 2.0 4 6 50 2
EMA010254 2.5 4 6 50 2
EMA010304 3.0 4 8 50 2
EMA010354 3.5 4 10 50 2
EMA010404 4.0 4 11 50 2
EMA010106 1.0 6 3 50 2
EMA010156 1.5 6 4 50 2
EMA010206 2.0 6 6 50 2
EMA010256 2.5 6 6 50 2
EMA010306 3.0 6 8 50 2
EMA010356 3.5 6 10 50 2
EMA010406 4.0 6 11 50 2
EMA010450 4.5 6 13 50 2
EMA010500 5.0 6 13 50 2
EMA010550 5.5 6 16 50 2
EMA010600 6.0 6 16 50 2
EMA010650 6.5 8 20 60 2
EMA010700 7.0 8 20 60 2
EMA010750 7.5 8 20 60 2
EMA010800 8.0 8 20 60 2
EMA010850 8.5 10 25 75 2
EMA010900 9.0 10 25 75 2
EMA010950 9.5 10 25 75 2
EMA011000 10.0 10 25 75 2
EMA011050 10.5 12 30 75 2
EMA011100 11.0 12 30 75 2
EMA011200 12.0 12 30 75 2
EMA011400 14.0 14 40 100 2
EMA011600 16.0 16 40 100 2
EMA011800 18.0 18 40 100 2
EMA012000 20.0 20 40 100 2
