Multiple Station Tablet Rotary Press ZPW23
This rotary tableting press is a continuous automatic tablet press for pressing granular raw materials into firm tablets. The equipment is a double-press type designed for industrial applications for large batch orders. Features of this rotary tableting press include stainless steel structure, transparent window, frequency conversion speed regulation, overload protection, safety protection device, etc.
Specification:
| Model | ZPW23 |
| Number of Stations | 23 |
| Main Compression Force (kN) | 80 |
| Maximum Tablet Diameter (mm) | 20 |
| Depth of Fill (mm) | 22 |
| Maximum Tablet Thickness (mm) | 10 |
| Max. Turret RPM (r/min) | 40 |
| Max. Output (pcs/h) | 55000 |
| Motor Power (kW) | 4 |
| Overall Size (mm) | 950x930x1850 |
| Approx. Net Weight (Kg) | 1500 |
