WN03RA250S Motorized Rotation Stages with Steeper Motor
WN03RA250S motorized rotation stage with stepper motor can realize full-automatic control. Featured with high precision worm gear structure, the stage can rotate forward and backward with minimal backlash.
The table size is φ230mm, center load capacity is 50kg, with an angle range of 360°.
| Model | WN03RA250S | |
| Structure | Angle range | 360° |
| Table size | φ230mm | |
| Worm gear ratio | 180∶1 | |
| Driving gear | Worm gearing | |
| Guide rail | Bearing | |
| Stepper motor ；(1.8°) | SST57D2121 | |
| Material | Aluminum alloy | |
| Surface | Blackened by anodic oxidation | |
| Center load capacity | 50kg | |
| Weight | 10kg | |
| Accuracy | Resolution | 0.001°(Non-MS driver) 0.0005°(20 MS driver) |
| Speed | 25°/sec | |
| Repeatability | 0.005°=18″ | |
| Run-out of top plate | 15µ | |
| Backlash | 0.005°=18″ | |
| Eccentricity | 5µ | |
| Step-out | 0.005°=18″ | |
