Hastelloy C-4 (UNS N06455) Corrosion-resistant alloy
Features
Hastelloy C-4 maintains outstanding stability and resilience to high temperatures to resist stress corrosion cracking. Adaptable to corrosive substances like mineral acid, chloride medium, acetic acid, acetic anhydride, sea water, etc.
Chemical Analysis
| % | Ni | Cr | Mo | Fe | C | Mn | Co | S | P | Ti | |
| Hastelloy B-4 | Min. | Balance | 14 | 14 | |||||||
| Max. | Balance | 18 | 18 | 3 | 0. 015 | 0. 02 | 2 | 0. 03 | 0. 04 | 0. 7 |
Physical Properties
| Density | 8.94G/CM3 |
| Melting Range | 1325-1370℃ |
The Min. Mechanical Properties under Room Temperature
| Alloy | Tensile Strength | Yield Strength | Elongation |
| RM N/MM2 | RPO.2 N/MM2 | A5% | |
| Solid Solution | 650 | 280 | 40 |
- Applications
- Chemical processing
- Nuclear fuel processing
