Application

Our DXL lubrication oil fine filters are applied for refined filtration of marine diesel engines and stationary diesel engines and testing equipment. The filters remove undissolved particles from lubrication oils.

Characteristics

DXL lubrication oil fine filters have a fabric screen with 3~10μm fineness, ensuring the cleanliness of the lubrication oil entering the engine.

Parameters
  • The case material commonly adopts Q235A
  • Working pressure ≤1.0Mpa
  • Working temp ≤80℃
  • The standard of flange is commonly GB2506-89 (optional)
  • When the filter dimension is bigger than sample, such as DN400, DN500, we can provide customization for our clients.
DN L1 L2 Q1 Q2 H1 H2 H3 H4 H P1 P2 D1 D C
80 220 220 200 400 110 440 50 190 750 160 360 325 200 160
100 220 220 200 410 125 975 45 215 1336 160 370 325 220 180
DN L1 L2 L3 H1 H2 H3 H4 H D1 R d D C
150 450 450 380 310 820 460 120 1730 620 322 24 285 240
200 530 530 530 360 900 555 100 1800 820 400 24 395 350
300 698 698 650 570 1090 820 100 2300 1120 500 40 445 400
350 748 748 748 570 1090 820 100 2300 1220 600 40 505 460
