Hastelloy X (UNS N06002) High-temperature alloy
Features
HASTELLOY X is a nickel- chromium- iron- molybdenum alloy with great resistance to oxidation under 1200℃. This alloy has outstanding cold and hot forming capabilities, and it should be heated to a starting temperature of 1175°C prior to processing.
Chemical Analysis
| % | Ni | W | Fe | Mn | C | Si | S | Cr | Mo | P | Cn | |
| Hastelloy X | Min. | Balance | 0.2 | 17 | - | 0. 05 | - | - | 20.5 | 8 | - | 0.5 |
| Max. | Balance | 1 | 22 | 1 | 0. 15 | 1.0 | 0. 03 | 23 | 10 | 0. 04 | 25 |
Standards
| Bar | Plate | Seamless Pipe | Welded Pipe | Seamless Pipe | Forging Part |
| ASTM B572 | ASTM B435 | ASTM B622 | ASTM B619 | ASTM B626 | ASTM BB5 |
Physical Properties
| Density | 8.94G/CM3 |
| Melting Range | 1260-1355℃ |
The Min. Mechanical Properties under Room Temperature
| Alloy | Tensile Strength | Yield Strength | Elongation |
| RM N/MM2 | RP0.2 N/MM2 | A5% | |
| HASTELLOY X | 660 | 240 | 35 |
- Applications
- Combustion chambers
- Gas turbine engines
- Fans and rollers in industrial furnaces
- Nuclear engineering
- Petrochemical industry
