750W Drive Motor Assembly ZD125B2-JY06
Your Motion
Application: electric material handling equipment
Technical Specifications
| Rated Power (W) | 750 |
| Rated Voltage(V) | 24 |
| No-load Revolution (RPM) | 3100±8% |
| No-load Current (A) | ≤8.0 |
| Rated Current (A) | ≤43.5 |
| Rated Torque(N•m) | 2.7 |
| Rated Revolution (RPM) | 2650±8% |
| Working Cycle (min.) | S2-60 |
| Insulation Class | F |
| Gear Ratio | 24.685:1 |
| Protection Level | IP44 |
| E-brake Voltage (V) | 24 |
| E-brake Torque (N•m) | 8 |
| Length (mm) | 243.2 |
Note: customization of PMDC brushed drive motor assembly is available upon your product requests and working conditions.
