WM-CLF01 4 Post Car Lift
Nearly 2 decades of experience in manufacturing custom vehicle maintenance equipment, our products have been exported to more than 60 countries
Our heavy duty 4-post car lift is a good choice for those with limited garage space. This kind of car lift features 4 hydraulic posts and a work platform. One car parks on the platform and is then lifted to a certain height. Then, another car can be parked under the first car. Although 4-post car lifts are more expensive than other types, they are powerful and help small but busy vehicle repair shops to keep up with customer demands.
We provide high-quality heavy-duty 4-post car lifts with a carrying capacity range of 3500-5000kg. Each car lift has been fully tested before delivery.
| Type | WM-CLF01 |
| Lift Capacity | 3500kg/4000kg/5000kg |
| Lift Height | Master：1500mm Slave：350mm |
| Min.Lift Height | 200mm |
| Lift Time | 50-60s |
| Platform Length | 4200mm/4500mm/5000mm |
| Platform Width | 550mm |
| Engine Power | 2.2kw-380v or 2.2kw-220v |
| Rated Oil Pressure | 24MPa |
| Pneumatic Pressure | 0.6-0.8MPa |
| Overall Weight | 1200kg/1250kg/1300kg |
1. Made of high-quality stainless steel with an electrostatic spraying process, the machine is beautiful and anticorrosive.
2. The distance of channel can be adjusted to adapt to vehicles with different wheel spans.
3. Equipped with a second lifting trolley to help operation.
4. The car can be locked on any position.
5. Equipped with control safety lock of steel wire rope to avoid breaking and ensure safe operation.
6. Customization service available.
- Hydraulic car
- Wire rope break-proof lock
