LPG Delivery Hose Type: LG25
The LPG delivery hose is widely used in various commercial and industrial transportation situations. The inner tube adopts rubber with conductivity lower than 106Ω/lg, which makes it resistant to oil or gasoline corrosion. It also serves as a safety function, protecting against sparks.
Advantages:
Application: Rubber hose designed for LPG (liquid petroleum gas), and petroleum products containing no more than 50% aromatic hydrocarbon;
Temperature Range: -30℃ ~ +80℃
Construction:
- Tube: Black composite rubber (oil and gas resistant, conductivity R＜106Ω/lg）
- Reinforcement: High strength composite fiber cord;
- Cover: Composite rubber (anti-aging, ozone resistance, and safety protection from sparks flying off in all directions);
Technical Parameters:
| Code No. | Size (inch) | I.D. (mm) | O.D. (mm) | W.P. | B.P. | Safety factor | MBR (mm) | Weight (Kg/m) | LengthMax (m) | ||
| (bar) | (psi) | (bar) | (psi) | ||||||||
| LG25-6 | 1/4〞 | 6.3 | 13 | 25 | 360 | 100 | 1450 | 4 | 40 | 0.14 | 100 |
| LG25-13 | 1/2〞 | 13 | 23 | 25 | 360 | 100 | 1450 | 4 | 78 | 0.35 | 100 |
| LG25-19 | 3/4〞 | 19 | 31 | 25 | 375 | 100 | 1500 | 4 | 110 | 0.62 | 100 |
| LG25-25 | 1〞 | 25 | 38 | 25 | 375 | 100 | 1500 | 4 | 150 | 0.82 | 100 |
| LG25-32 | 1-1/4〞 | 32 | 45 | 25 | 375 | 100 | 1500 | 4 | 200 | 0.99 | 100 |
| LG25-38 | 1-1/2〞 | 38 | 52 | 25 | 375 | 100 | 1500 | 4 | 250 | 1.19 | 100 |
| LG25-51 | 2〞 | 51 | 67 | 25 | 375 | 100 | 1500 | 4 | 350 | 1.80 | 100 |
| LG25-64 | 2-1/2〞 | 64 | 81 | 25 | 375 | 100 | 1500 | 4 | 420 | 2.28 | 100 |
| LG25-76 | 3〞 | 76 | 94 | 25 | 375 | 100 | 1500 | 4 | 500 | 2.73 | 100 |
| LG25-89 | 3-1/2〞 | 89 | 107 | 25 | 375 | 100 | 1500 | 4 | 550 | 3.14 | 61 |
| LG25-102 | 4〞 | 102 | 120 | 25 | 375 | 100 | 1500 | 4 | 650 | 3.55 | 61 |
| LG25-127 | 5〞 | 127 | 149 | 25 | 375 | 100 | 1500 | 4 | 800 | 5.20 | 61 |
| LG25-152 | 6〞 | 152 | 174 | 25 | 375 | 100 | 1500 | 4 | 950 | 6.14 | 61 |
