D8140SWW 24V 10mm Dimmable Color Changing LED Strip Light

D8140SWW 24V 10mm Dimmable Color Changing LED Strip Light
D8140SWW 24V 10mm Dimmable Color Changing LED Strip Light
D8140SWW 24V 10mm Dimmable Color Changing LED Strip Light
D8140SWW 24V 10mm Dimmable Color Changing LED Strip Light
: http://ledstripsolution.us/5-2-digital-rgb-white-led-strip-light.html
Features
  • This dimmable LED strip has feature of adjustable correlated color temperature.
  • This LED strip is self-encapsulated to provide 5 optional white lights of 2700-6000K.
  • The 1BIN/2BIN delivery is provided with high color consistency.
  • The color changing LED strip adopts high quality FPC and high thermal 3M adhesive, so it is of good heat dissipation.
  • This LED strip has high color rendering index of 80/95, making it able to truly represent the real color of the object.
  • Its service life is over 36000H.
  • This LED strip can widely match with various kinds of controllers.
Basic Parameters
Size 5000x10x1.5mm
Cutting unit 14LEDs/100mm
Input voltage 24VDC
Input current 0.713A/1m & 3.2A/5m
Typical power 17.1W/m
Max. power 19.2W/m
Bend diameter ＞60mm
Photo-electric parameters
Color rendering index >80 >95
Correlated color temperature 2700K ~ 6000K
Lumen (m) 1900/1273
Luminous efficiency(W) 111/75
Energy efficiency class A+
Recommended profiles
  • LS1613(B)
  • LE2507
  • LE2513
