LED Track Light
Application
LED track light is suitable for usage in clothing stores, jeweler’s, supermarkets, department stores, hotels, living rooms, cafeterias, bedrooms, exhibition halls and museums.
| Model | |||||
| Input voltage | AC100~277V | AC100~277V | AC100~277V | AC100~277V | AC100~277V |
| Power | 10W | 20W | 30W | 40W | 50W |
| PF value | ＞0.95 | ＞0.95 | ＞0.95 | ＞0.95 | ＞0.95 |
| Lamination | 1250lm | 2500lm | 3750lm | 5000lm | 6250lm |
| CRI | ＞80 | ＞80 | ＞80 | ＞80 | ＞80 |
| Luminous efficacy | ≥125lm/W | ≥125lm/W | ≥125lm/W | ≥125lm/W | ≥125lm/W |
| Lighting angle | 15°/24°/40°/60° | 15°/24°/40°/60° | 15°/24°/40°/60° | 15°/24°/40°/60° | 15°/24°/40°/60° |
| Working temperature | -20~50℃ | -20~50℃ | -20~50℃ | -20~50℃ | -20~50℃ |
| Warranty | 3 years | 3 years | 3 years | 3 years | 3 years |
| Dimensions(L*W*H) | Φ50*85mm | Φ75*110mm | Φ100*125mm | Φ100*135mm | Φ100*155mm |
| Net weight | 320g | 510g | 730g | 950g | 1300g |
Feature
1.LED track light uses 6063 aviation aluminum material and adopts a hollow-out design and surface oxidized paint baking technique to achieve anti-oxidation, erosion resistance, heat convection and other properties.
2.LED track light features multiple lighting angles to satisfy lighting requirements of various working conditions.
3.The COB light source of LED track light adopts EMC reverse installation technique to receive better heat emission and excellent heat endurance.
4.The bracket supports left/right rotation, the lamp body supports vertical spinning, so that the LED track light can fulfill lighting requirements from all directions and angles.
5.LED track light uses high quality, efficient and intelligent IC control as power supply to achieve overheat protection, short circuit protection, surge impulse resistance and high constant current precision, and therefore guarantees steady luminous power and extend service life of the product.
6.LED track light adopts the light source with high luminous efficacy so that the product is smaller and more energy efficient than likewise products in the market while retaining the same brightness level.
1. Fix the guide rail to the ceiling with screws, as the following drawing.
2.Fix the lamp on the guide rail，rotate the knob 90 degrees to fix it on the track according to the following drawing.
3. Make sure the switch is off, connect the wire cable as the diagram, then make sure that the input voltage is within the specified range, the lamp is lighting after turning on the switch.
Hongsheng provides a variety of indoor and outdoor LED lighting products, a reliable LED track light manufacturer and supplier with rich experience in making LED modules and LED lights. The LED track light can be applied for supermarket lighting, hotel lighting, retail store lighting, kitchen lighting, shop lighting, exhibition lighting, bedroom lighting and so on. There are wide range of cost effective LED products available with 10W LED track light, 20W LED rail light, 30W LED track light, 40W LED track light, 50W LED track light fixture, etc. With certificates like PSE, ROHS, CE and ETL, we are contributed to providing energy saving LED lights and LED lighting solutions for customers.
