1800×1000mm Auto Feeding Large Format Camera Positioning CO2 Laser Cutter, CMA1810-FV-E Laser Cutting with auto feed system Manufacturer

1800×1000mm Auto Feeding Large Format Camera Positioning CO2 Laser Cutter, CMA1810-FV-E Laser Cutting with auto feed system

: http://lasercut-group.com/1-5-14-single-head-co2-laser-cutting-machine.html

Applicable Materials
The CMA1810-FV-E laser system is applicable for different kinds of textile fabric materials like cotton, fabric, leather, paper and so on.

Cutting System

Model	Laser power (W)	Laser head	Working area (mm)	Overall dimension (mm)	Weight (Kg)	Repeated positioning accuracy (mm)	Speed (m/min)	Supply voltage	Working environment
CMA1810-FV-E	60~130	Single	1800×1000	2500×2140×1950	930	±0.1	0~30	220~240V, 50/60Hz	Temp: 5~40°C, Humidity: 5~80%. No condensate water, no dust or less dust.

Laser Processing Examples:

Cloth shoes laser cutting
Clothing laser cutting hollowing and carving
Fabrics laser cutting and hollowing
Fabric laser cutting
Fabrics laser cutting and carving
Fabrics laser cutting
Garment accessories lace laser cutting
Non-woven fabrics laser cutting

Product Feature
1. The system achieves a full format pattern recognition with just one shot, thus significantly improving the camera’s automatic positioning efficiency.
2. Wide vision: a large format cutting is easily handled with this system.
3. Automatic contour extraction function, no need to set up a template. Easy operation and efficient.
4. Processing parameters can be directly set in order to achieve perfect cutting.
