6T Telescopic Crawler Crane, STSQ6L
This 6-ton telescopic crawler crane is perfectly suited for muddy ground and mountainous terrain due to its compact structure and small turning radius. The maximum extension length of telescopic boom is up to 20 meters. The 360-degree rotating platform makes daily operation and maintenance easier.
Features
- Excavator crawler track is adopted for its good adaptability and gripping ability, allowing for moving through muddy ground and mountainous terrain;
- Customer-specific double-section hydraulic outrigger eliminates the need for vehicle loading ramp, ensuring high loading efficiency;
- Able to lift and move in hard-to-access areas, ground clearance of 350mm;
- Max. loading capacity
- 6t
- Max. lifting height
- 20m
- Outrigger span (longitudinal* transversal)
- 5.1m*5m
- Boom
- 5 sections (5m per section)
- Dimensions
- 6.19m*1.95m*2.25m
- Engine model
- Changchai 4G33
- Engine power
- 52kW
- Gearbox
- planetary reducer
- Slewing speed
- 2.8r/min
- Crane weight
- 9000kg
