LCK6125A Coach (Compass)

: http://zhongtongbuses.com/1-5-4-lck6125a-coach/index.html

This bus is specially designed for Africa market with Cummins engine in front. It features excellent cooling system, strong power, and low fuel consumption. The electric retarder works to enhance braking capacity, shorten braking distance and make the vehicle much safer. The metal covering in the front wall enhances the coach's safety. The coach possesses a powerful passing ability with the approaching angle reaching 13°.

Overall specification	overall dimension (mm)		12500	Engine	engine model	L360 20
	overall width (mm)		2550		manufacturer	Cummins (China)
	overall height (mm)		3850/3710		engine position	Front
	body inside height (mm)		1940		engine type	6 cylinders in-line, turbocharged with intercooler
	wheel base (mm)		5800 1350		max power (kw)	264
	front/rear overhang (mm)		2340/3150		max torque (N.M)	1480
	approach/departure (º)		10/13		displacement (l)	8.9
	first step height (mm)		400		bore/stroke mm	114X144.5
	max g.v.w.kg		21500
	seats capacity (person)		61 1/ 70 1
	max speed (km/h)		120
	luggage cabin (m³)		10.4
Items		Standard					Optional
Chassis specification	manufacturer	made in Zhongtong
	gear box	S6-160, ZF technology, six gears
	clutch	coil spring, Ø430
	front axle	7.5t front axle
	rear axle	13t rear axle
	third axle	5t third axle
	suspension	multi-leaf spring suspension
	steering	integral assistant power steering
	brake	dual circuit air braking, drum brake
	fuel tank	400L 400L
	tyre	315/80R22.5
	battery /dynamo	2×12V/195Ah / 28V /150A 140A
	others	brake slack auto adjuster, electric retarder, ABS
	seat	adjustable seats, ZTZY3210 2 2 layout 61 1; fixed seats, ZTZY3072, 3 2 layout 70 1; driver seat ZTZY1050
