Brackish Groundwater Desalination Brackish Water Reverse Osmosis (BWRO) System
Brackish Groundwater DesalinationBrackish Water Reverse Osmosis (BWRO) System
The JHH-BW series brackish groundwater desalination plant (available in a large or medium size) is designed for saline-alkali area and salt-water encroached land. Brackish water contains more saline than fresh water and is too salty to be used without treatments. Using unique technology, our products offer an excellent solution with the purified water conforming Guidelines for Drinking Water Quality released by the WHO and National Standard for Drinking Water Quality.
Our RO system produce direct drinking water by eliminating the harmful effects of heavy metals, bacteria, and more as the system utilizes a semipermeable membrane that separates an extremely high percentage of unwanted molecules and materials.
Features:- Using a PLC automatic control system, the plant works automatically.
- Equipped with an on-line water quality monitor, users can carry out real time monitoring of the produced water quality.
- Feed salinity: 1000-10000mg/L
- Rejection: ≥98%
- Feed temperature: 2-40℃
- Output salinity: ≤500mg/L
- Recovery: 10-65%
- Power: 380V/50Hz or 220V (440V)/60Hz
| Model | Output capacity (m³/h) | Operational pressure(Mpa) | Electri-comsumption(Kwh/T) | Dimension(mm) | Construction |
| JHH-BW2 | 0.1 | 1.5-4 | 11 | 580×440×1600 | Vertical |
| JHH-BW5 | 0.25 | 1.5-4 | 8 | 650×440×1600 | Vertical |
| JHH-BW10 | 0.5 | 1.5-4 | 4.4 | 800×600×1700 | Vertical |
| JHH-BW20 | 1 | 1.5-4 | 4 | 2500×900×1600 | |
| JHH-BW50 | 2.5 | 1.5-4 | 3 | 2500×1200×1600 | |
| JHH-BW100 | 5 | 1.5-4 | 2.2 | 2500×1500×1800 | |
| JHH-BW200 | 10 | 1.5-4 | 2 | 3400×1500×1800 |
