EC (Easy Control) Industrial Borescopes Manufacturer

EC (Easy Control) Industrial Borescopes

: http://videoscopesupplier.com/1-5-ec-industrial-borescopes.html

EC (Easy Control) industrial borescopes are exceptionally scalable and feature hoses with different diameter and length specifications, with diameter ranging between 2.8mm to 6.5mm. Equipped with appropriate hose lens, the borescopes can be used in a variety of fields. The interface of our borescopes meets international standards, and the cameras utilize different pixel levels depending on customer needs, with a maximum of 2 milling pixels.

Features

A probe wire can be inserted and replaced, with different pixels, lengths, diameters and light sources.
Probe wire diameter: 6.5mm/6.0mm/4.3mm/3.9mm/2.8mm
Camera pixel: 2 million pixels/1 million pixels/480,000 pixels
Light source: infrared source/ white-light source/UV light source
Portable and integrated body allows users to carry out all functions, including bending, photo taking, and image processing with just one hand.
5" HD 4:3 digital touch LCD for clearer high-resolution true-color images
360°mechanical mute bending, with bending with stop
18650 lithium battery & alternating current dual power supply; easy battery replacement; duration of working time over 3 hours
HD HDMI output; WiFi/bluetooth/wireless emission/multi-mode image sharing

EC SPECIFICATION

PROBE Replaceable	Pixel:	480,000 Pixel / 360,000 Pixel
	Diameter:	6.0mm / 4.3mm / 3.9mm / 3.0mm /2.8mm
	FOV:	90°
	View Direction	Farward View/ Farward view+Side view Dual Camera
	Probe Length	1~8 meters with tungsten mesh
	Articulation	4 Ways Mechanical control
SYSTEM	Displayer	5 Inch Touch Screen LCD
	Memory	TF Card Support 8G~128G
	Output Interface	USB2.0/HDMI out/ Earphone out
	Power	2x18650 Li-battery/110~220V AC
	Wireless	WiFi/Bluetooth for Android
	Size	305135110 （LWH）
	Weight	0.78Kg （Include Battery）
	Waterproof	Probe: IP67
	Working Temperature	-10～50°
Software	Menu	Touch Screen control
	Image process	Image Zoom In&Out; Image Size & Color Editing; Image Contrast system; Image & Folder Rename
	Lightness	5 level LED/ Fibre light adjust （can support IR Light + White Light Dual Light Source） 5 level image brightness adjust
	Storage	Image/Video/Audio record
	Language	English/Chinese/French/Korean/German/Russian/Japanese/ etc.
