High Speed Rotary Tableting Press GZPK370
Applications
The high speed rotary tableting press GZPK370 is a rotary tablet press for pressing tablets out of granular materials. It is mainly adopted for applications in pharmaceutical, foodstuff, chemical and electronics industries.
Features of the High Speed Rotary Tableting Press GZPK370
- This high speed rotary tableting press adopts frequency speed control.
- It has an air intake adjuster for eliminating dust from the tablet pressing chamber.
- Accurate tablet weight control system enables easy rejection of degraded tablets in batches or individually.
- Various types of impellers are available for different material types.
Specification:
| Model | GZP(K)-26 | GZP(K)-32 | GZP(K)-40 | GZP(K)-44 |
| Number of Stations | 26 | 32 | 40 | 44 |
| Tooling Type | D | B | BB | BBS |
| Main Compression Force (kN) | 80 | 80 | 80 | 80 |
| Pre Compression Force (kN) | 20 | 20 | 20 | 20 |
| Maximum Tablet Diameter (mm) | 25 | 18 | 13 | 11 |
| Depth of Fill (mm) | 16 | 16 | 16 | 16 |
| Maximum Tablet Thickness (mm) | 6 | 6 | 6 | 6 |
| Max. Output (pcs/h) | 140000 | 192000 | 264000 | 291000 |
| Motor Power (kW) | 7.5 | 7.5 | 7.5 | 7.5 |
| Overall Size (mm) | 1200x950 x1850 | 1200x950 x1850 | 1200x950 x1850 | 1200x950 x1850 |
| Approx. Net Weight (Kg) | 1700 | 1700 | 1700 | 1700 |
