Heat Pump Drying System
Developed by Xinzhou, this heat pump drying system reuses heat from the dehumidification unit, as well as heat produced by the equipment itself, thus resulting in an energy saving and faster drying performance.
As one type of low temperature drying equipment, the heat pump drying system is designed for drying agricultural products, such as shiitake mushrooms, wheat, rice, vegetables, and more. A low nutrient loss is guaranteed, as is an appealing appearance.
- Tea
- Incense Stick
- Peanut
- Ceramics
- Shiitake Mushroom
- Paper
Xinzhou offers clients a series of heat pump drying systems, parameters of which are listed below. We also offer customization services.
Reference:
Ambient Temperature: 20℃
COP Value: 3.8
Parameters of XZST-03-I and XZST-O3-Ⅱ Heat Pump Drying System| Model | Compressor Power (Kw) | Rated Heat | Fan Heater Power (KW) | Cooling Fan Power (Kw) | Circulating Air Volume (m³/h) | Noise | Dimension | Voltage/Frequency | Highest Hot Air Temperature | Ambient Temperature Range | Freezing Medium | |
| External Machine for Cooling | Internal Machine for Heating | |||||||||||
| XZST-03-I | 10.5KW | 2.2KW | 0.25KW | 0.25KW | 3200 m³/h | 65dB(A) | 680x360x1060 | 720x680x800mm | 380V~/3N/50HZ | High Temperature Type: 80°C Common Type: 60°C | 20-43°C | Mixing Freezing Mediums |
| XZST-O3-Ⅱ | 10.5KW | 2.2KW | 1.1KW | 0.25KW | 3200 m³/h | 65dB(A) | 680x360x1060 | 720x680x800mm | ||||
| Model | Compressor Power (Kw) | Rated Heat | Fan Heater Power (KW) | Cooling Fan Power (Kw) | Circulating Air Volume (m³/h) | Noise | Dimension | Voltage/Frequency | Highest Hot Air Temperature | Ambient Temperature Range | Freezing Medium | ||
| External Machine for Cooling | Internal Machine for Heating | ||||||||||||
| XZST-05-I | 18KW | 3.7KW | 0.35KW | 0.35KW | 5600 m³/h | 65dB(A) | 820x820x980 mm | 840x840x850mm | 380V~/3N/50HZ | High Temperature Type: 80°C Common Type: 60°C | 20-43°C | Mixing Freezing Mediums | |
| XZST-05-Ⅱ | 18KW | 3.7KW | 2.2KW | 0.35KW | 5600 m³/h | 65dB(A) | 820x820x980 mm | 840x840x850mm | |||||
| Model | Compressor Power (Kw) | Rated Heat | Fan Heater Power (KW) | Cooling Fan Power (Kw) | Circulating Air Volume (m³/h) | Noise | Dimension | Voltage/Frequency | Highest Hot Air Temperature | Ambient Temperature Range | Freezing Medium | |
| External Machine for Cooling | Internal Machine for Heating | |||||||||||
| XZST-10-I | 35KW | 7.5KW | 0.75KW | 4KW | 11000m³/h | 70dB(A) | 880x1280x1350mm | 1400x980x900mm | 380V~/3N/50HZ | High Temperature Type: 80°C Common Type: 60°C | 20-43°C | Mixing Freezing Mediums |
| XZST-10-Ⅱ | 35KW | 7.5KW | 0.75KW | 4KW | 11000m³/h | 70dB(A) | 880x1280x1350mm | 1400x980x900mm | ||||
- Energy Saving: Replacing heating the air stove by fuel, heat pump drying system uses a heat pump to heat the air, leading to 40%-70% heating cost reduction.
- Environmental Protection: By using flammable materials for heating, conventional drying equipment is harmful to human health and pollutes the environment by discharging toxic gases. To combat this, our heat pump drying system produces no harmful gases, thus ensuring employee safety and protects the environment.
- Easy Operation: No operator is needed for monitoring after installation and commissioning, as the heat pump drying system will automatically operate.
- Modular Design: When the drying area is very large, a heating device can be added. Through equal distribution, a more uniform heating is achieved.
