Huilong automatic self-cleaning filter is appropriate for the filtration of contaminated low-viscosity and high-viscosity liquids in a wide range of fields and industries such as construction machinery, heavy duty engines, machining equipment, chemical industry, food industry and so on.

Technical Specifications
  • Operating pressure: max. 4MPa
  • Operating temperature: 5℃~80℃
  • Filter housing: carbon steel, stainless steel
Filter Type Port Size Photo No. Rated flow H D D1
F10 F20
ZGQ(D)025 G1/2 M22×1.5 1 22 58 142 86 50
ZGQ(D)045 G3/4 M27×2 1 45 67 192 116 70
ZGQ(D)160 G1-1/2 M48X2 2 155 240 385 128 115
ZGQ(D)240 DN50 2 240 335 430 350 146
ZGQ(D)330 DN80 2 330 450 520 350 146
