Injection Mold for Door Armrest
Injection Mold for Door Armrest
Our client used to have two sets of molds for each product and required 24 hours to switch between different production applications, leading to a poor efficiency. After working with a specialist, we designed and optimized plan to shorten the switching time to half an hour and increased the customer’s production and economic efficiency.
| Project: Door Armrest | Country: UK |
| Brand: Aston Martin | Product: MLDG DR A/RST LH+RH |
| Material:PA66+33%GF | Steel: XPM |
| Cavity:1+1 | Gating solution:2 Drop YUDO Hot Runner With Hot Tip |
| Mold size:670*950*697 | Product dimension:647*128*96 |
| Injection machine: 800 T |
| Project: Door Armrest | Country: UK |
| Brand: Aston Martin | Product: INSERT FRT DR A/RST LH+RH |
| Material: ABS | Steel: XPM |
| Cavity:1+1 | Gating solution: Drop YUDO Hot Runner With Hot Tip |
| Mold size:400*400*500 | Product dimension:191.2*130*40 |
| Injection machine: 320 T |
