TOP-420 Intermittent/Full Rotary Cutting Machine
The TOP-420 rotary die cutting machine is designed for digital label converting and finishing, and the die cutter works in both semi rotary and full rotary modes. Multiple functions of the intermittent rotary cutting machine include flexographic UV printing (varnishing and cold foil), IML die cutting, slitting, and sheeting. The full rotary cutting machine is user-friendly and easy to operate.
| Max Speed | 300RPM |
| Accuracy of Cutting | ±0.15mm |
| Max Die Cutting Area | 381mm ×410mm (L×W) |
| Paper Width | 80mm ---420mm |
| Max Unwinding Dia. | φ700mm (about 2000Meters ) |
| Max Rewinding Dia. | φ700mm (about 2000Meters ) |
| Magnetic Cylinder | 120Teeth 1/8 CP ( Standard ) |
| Cylinder Range | 120T~160T |
| Length of Die Cutting | 50mm ~330mm |
| MOTOR Power | 10 KW |
| Overall Diameter ( L × W × H ) | 2900mm ×1200mm×1500mm |
| Weight | 2900KG |
Unwinder--Web Guider--Hot Laminator--Semi-Rotary Die Cutter--Rewinder
A: Web guiding system
B: Tension control system
C: Flexo for UV coating
D: UV 160W/CM or 200w/cm
E: 192 teeth magnetic cylinder
F: HMI touch screen operating system
F: Waste matrix mandrels
