Vacuum Weighing Bagging Machine
The vacuum weighing bagging machine carries out two-side vacuum packaging, three-dimensional vacuum packaging, automatic packaging, measurement, shaping, vacuum, sealing, transportation and one machine dual-purpose. It is primarily used for vacuum packaging of granular materials such as rice, grain, soybeans and peanuts.
This vacuum packaging machine will pack goods placed in a vacuum chamber, and discharge air through the vacuum pump, thus forming a vacuum environment. A heating process is then used to instantly close the bag mouth in order to complete the vacuum packaging process. This effectively prevents the food from spoiling.
Weighing range: 0.25-5.0kg
Division value: 2-5g
Weighing error: ±0.2%F.S
Weighing speed: 300 (six-sided vacuum) Bag/h
240 (two-sided vacuum) Bag/h
The flat part of vacuum packaging: up and down, left and right, forward and backward (six-sided vacuum) up and down (two-sided vacuum)
Voltage: AC380V±5% 50HZ
Power consumption: 2.5KW
Air consumption: 0.6Mpa, compressed air 3 m3/h
Vacuum degree: -0.7Mp~0.0Mp (Adjustable)
Dimension (length * width * height): 1420×1460×2240mm
- The vacuum weighing bagging machine uses a weighing controller and a three-stage feeding mechanism, as well as a feeding speed slow down action using vibration before the materials reach the target. This is adaptable to a number of different materials.
- The core components use high-precision alloy steel sensors, AirTAC pneumatic components, a high-definition English touch screen, as well as components sourced from Siemens, PLC and other internationally known brands, thus ensuring the quality.
- The vacuum weighing bagging machine features a small volume of 1420mm *1460mm *2240mm, and is a single operation machine. This ensures the ease of use and high efficiency, with an output of 300 bags/hour.
- A unique, three-dimensional pressure shaping device and two-side pressure shaping device compacts surfaces that need to be pressed and smoothed, ensuring the outstanding effects, low noise, single sealing process, and high success rate.
