Mining Shaking Table

: http://embroidery-equip.com/6-5-rhinestone-shaking-machine.html

Application
Mining shaking table can be used in sorting out different granularity materials including coarse sand(2-0.5mm), fine sand (0.5-0.074mm), sludge(-0.074) and so on. It can be used in sorting out iron and manganese ore as well. The effective recycling granularity scope of shaking table is 2-0.22mm when processing ore like tungsten, tin and so on.

Applicable materials
Copper ore, pyrrhotite, hematite, limonite, molybdenum ore, gold ore, iron ore, aluminum ore lead ore, zinc ore, coal and so on.

More Details

Parameters

Type	Coarse sand table	Fine sand table	Groove table
Table size (mm)	4436X1825X1536
Stroke length (mm)	16~22	10~16	10~16
Stroke frequency (r/min)	240~290	300~320	330~340
Water consumption(t/h)	190	80	50
Handling capacity(t/h)	30	8	8
Feeding granularity(mm)	2~0.2	0.5 ~0.037	0.074~0.019
Feeding concentration(%)	20~25	15~20	15~20
Minimum installation slope (° )	2°30"	1°50″	0°45"
Overall dimension(mm)	5454X1825X1242
Adjusting range of stroke length (mm)	8~22
Power (kW)	1.5
Weight (kg)	1012

Advantages

The horizontal slope adjustment range of mining shaking table is 0～10° and it is easy to adjust stroke length.
The table is smooth and it has good ability of corrosion resistance and deformation resistance. It is easy to do sectional repair.
The table can keep running steadily when horizontal slope and stroke length are being changed.
The spring is placed in the cabinet and its structure is compact.
The shaking mechanism runs reliable, which has few easy wearing parts and doesn’t leak oil.
The shaking table will not consume the potion and it is power saving.
