Mobile Crushing Plant
The wheel mounted crushing plant can be equipped with jaw crusher, impact crusher, and cone crusher. The material is conveyed to the crusher by the feeding machine of the mobile crushing plant. Upon the completion of primary crushing, the material will be processed with circular vibrating screen, to realize circular crushing. The material with the granularity conforming to specification will be discharged by the conveyor of the crushing system.
Based on actual production demand, the circular vibrating screen of the wheel mounted crushing plant can be dismantled for direct primary crushing of the raw material. The processed material will be delivered to other crusher directly for further processing.
Technical Parameters
Mobile Crushing Plant with Jaw Crusher| Model | YZ938E69 | YZ1149E75 | YZ1349E90 |
| Transport Route Length (mm) | 11900 | 13100 | 14600 |
| Transport Route Width (mm) | 2550 | 2550 | 2950 |
| Transport Route Height (mm) | 3650 | 4450 | 4500 |
| Max. Length (mm) | 12100 | 13300 | 14600 |
| Max. Width (mm) | 2900 | 2950 | 3300 |
| Max. Height (mm) | 4060 | 4810 | 5300 |
| Weight (ton) | 36 | 57 | 83 |
| Tire Configuration | Dual axis | Triple axis | Triple axis |
| Crusher Model | PE600 x 900 | PE750 x 1060 | PE900 x 1200 |
| Max. Feed Material Granularity (mm) | 480 | 630 | 750 |
| Outlet Adjustable Range (mm) | 65-160 | 80-140 | 95-165 |
| Handling Capacity (t/h) | 90-180 | 110-320 | 220-450 |
| Feeder Model | ZSW380 x 96 | ZSW490 x 110 | ZSW490 x 130 |
| Model of Main Belt Conveyor | B800 x 8.5M | B1000 x 9M | B1200 x 9.5M |
| Side Belt Conveyor Model (optional) | B450 x 3M | B500 x 3.5M | B650 x 4M |
| Generator Set (optional) (kW) | 180 | 220 | 250 |
Mobile Crushing Plant with Impact Crusher
| Model | YZ938F1210 | YZ1149F1214 | YZ1149F1315 |
| Transport Route Length (mm) | 11900 | 11900 | 13100 |
| Transport Route Width (mm) | 2550 | 2600 | 2900 |
| Transport Route Height (mm) | 3900 | 3900 | 4450 |
| Max. Length (mm) | 12100 | 12100 | 13300 |
| Max. Width (mm) | 2900 | 2950 | 2950 |
| Max. Height (mm) | 4310 | 4310 | 4810 |
| Weight (ton) | 39 | 44 | 54 |
| Tire Configuration | Dual axis | Dual axis | Triple axis |
| Crusher Model | PF-1210 | PF-1214 | PF-1315 |
| Max. Feed Material Granularity (mm) | 300 | 300 | 350 |
| Handling Capacity(t/h) | 70-130 | 90-180 | 120-250 |
| Feeder Model | ZSW380 x 96 | ZSW490 x 110 | ZSW490 x 110 |
| Model of Main Belt Conveyor | B800 x 8.5M | B1000 x 9M | B1000 x 9M |
| Side Belt Conveyor Model (optional) | B450 x 3M | B500 x 3.5M | B500 x 3.5M |
| Generator Set (optional) (kW) | 220 | 270 | 350 |
Mobile Crushing Plant with Cone Crusher
| Model | Y3K1548B75 | Y3K1860B160 |
| Transport Route Length (mm) | 14000 | 15200 |
| Transport Route Width (mm) | 3100 | 2830 |
| Transport Route Height (mm) | 4300 | 4350 |
| Max. Length (mm) | 14000 | 16400 |
| Max. Width (mm) | 3400 | 3400 |
| Max. Height (mm) | 4700 | 4700 |
| Weight(ton) | 34.5 | 47.5 |
| Tire Configuration | Dual axis | Triple axis |
| Crusher Model | B75 | B160 |
| Belt Conveyor for Material Discharging | B650 x 7M | B800 x 7.5M |
| Belt Conveyor for Returned Material 1 | B650 x 9.5M | B800 x 9.5M |
| Belt Conveyor for Returned Material 2 | B650 x 5M | B800 x 6M |
| Belt Conveyor under Vibrating Screen | B800 x 6M | B800 x 7M |
| Vibrating Screen Model | 3YK1548 | 3YK1860 |
