Hydraulic Tong


Hydraulic tong is an ideal wellhead tool used for making up and breaking outdrill pipe. It is widely used for oil and gas drilling operations. This hydraulictong is designed and manufactured according to SY5074-85 standards. It has many advantages overelectric or pneumatic drive tons, like higher reliability, smaller size andlighter weight, larger torque, and better flexibility. In addition, our hydraulictong uses less wearing parts. As this tong uses three-point planetary cammechanism, it achieves a wide tightening range and can tighten the pipes andcouplings without changing dies.

Parameters of
HydraulicTong

1.     Suitable range (mm): Φ40-Φ89

2.     Ratedtorque at low speed (KN*m): 3.2

3.     Ratedtorque at high speed (KN*m): 1.2

4.     Max.torque (KN*m): 4.0

5.     Rotatespeed at low speed (r/min): 36

6.     Rotatespeed at high speed (r/min): 120

7.     Max. opening of main tong/ backup tong (mm): 95/116

8.     Max. transport weight (K): 102

9.     Rated torque of oil motor (N*m): 400

10. Rated rotate speed of oil motor (r/min): 255

11. Rated capacity of oil motor (l/min): 80

12. Rated differential pressure of oil motor (Mpa): 10

Dezhou RundongCompany is an ISO9001 certified hydraulic tong manufacturer and supplier,located in China.We provide fishing tool, cementing tool and hose, etc. We can also providecustomized equipment and accessories according to customer’s specialrequirements and equipment needs. If you have any interest in our products,please click on the related pages or contact us directly. We look forward tohearing from you.
