Vinyl MQ Silicone Resin

: http://srsilicone.com/14-5-1-vinyl-mq-silicone-resin/index.html

Models: SCR5609-24, SCR5609-33, SCR5609-22C
Feature: With reactive polysiloxane of special structure
Applications: The liquid silicone resin is mainly used as reinforcing filler, or tackifier for pressure sensitive adhesive
Packaging: 20kg/pail, 200kg/pail

Typical Properties

Physical properties	Test method	Unit	SCR5609-24	SCR5609-33	SCR5609-22C
Appearance	Visual		Colorless and transparent	Colorless and transparent	Colorless and transparent
M/Q			1.05	1.05	1.1
Viscosity	DIN53019	mPa.s ( 25 ℃ )	(5.0-5.5)x10⁴	(5.0-5.5)x10⁴	(2.0-2.5)x10⁴
Resin content		%	100	100	100
Vinyl content	Chemical titration	mmol/g	0.9	1.22	1.74
Volatility	150 ℃ x3hours	%	< 2.5%	< 2.5%	< 3%

Notes:
1) Store the silicone oil at room temperature in an indoor dry and ventilated place without direct sunlight. Shelf life is 12 month.
2) Parameters in the table are only for reference use. Contact us for more details.

Models: SCR5609-20, SCR5609-30, SCR5609-35, SCR5609-05
Feature: With reactive polysiloxane of special structure
Applications: The solid silicone resin is mainly used as reinforcing filler, or tackifier for pressure sensitive adhesive
Packaging: 20kg/pail, 200kg/pail

Typical Properties

Physical properties	Test method	Unit	SCR5609-20	SCR5609-30	SCR5609-35	SCR5609-05
Appearance	Visual		Colorless and transparent	Colorless and transparent	Colorless and transparent	Colorless and transparent
M/Q			0.8	0.8	0.8	0.8
Resin content		%	68-70	68-70	68-70	68-70
Vinyl content	Chemical titration	mmol/g	0.74	1.11	1.29	0.18
Volatility	150 ℃ x3hours	%	< 1.5%	< 1.5%	< 1.5%	< 1.5%
Resin is soluble in silicone oil
