Multihead Packing Machine
Features
1. This multihead packing machine is designed for packaging, dosing and weighing regular and irregularly shaped materials, such as candy, sunflower seed, potato chip, happy fruit, peanut, jelly, freezing rice dumpling, biscuit, chocolate, nut, pet food, puffed food, small metal parts and plastic parts, etc.
2. This packing machine is equipped with precision digital measuring device, and its operating system comes with LCD display screen and can display operations in multiple languages, including English, Russian, German, Spanish and Italian, etc.
3. IP65 waterproof and dustproof design. It's easy to clean and maintain.
4. Able to self-adjust during running.
5. Operation menu available to make you study and operate it more easily. The multihead packing machine is also designed with automatic data statistic function.
6. Optional configurations of this multihead packing equipment include printing equipment, suction hopper, and more.
7. High compatibility and compact structure.
8. This vertical packing machine can greatly save on materials and labor cost.
| Model | LTP-500 | LTP-600 | LTP-800 | LTP-900 |
| Packing speed | 50bags/min | Max 50 bag/min | 50 bags/min | 45 bag/min |
| Bag size | (L)60-300mm (W)90-200mm | (L)80-350mm (W)100-250mm | (L)20-400mm (W)100-300mm | (L)20-450 mm (W)140-350 mm |
| Bag making mode | Pillow-type bag, standing bag, punch | Pillow-type bag, standing-bevel bag, punch bag | Pillow-type bag, standing-bevel bag, punch bag | Pillow-type bag, standing-bevel bag, punch bag |
| Range of measuring | 150-1300ml | 150-2000ML | 3000ML | MAX 4000 ML |
| Max packaging film width | 420mm | Max 520mm | Max 620mm | Max 730 mm |
| Thickness of film | 0.04-0.09mm | 0.04-0.09mm | 0.04-0.09mm | 0.06-0.12 mm |
| Air consumption | 0.8Mpa 0.5cmb/min | 0.8Mps 0.4m3/min | 0.8Mps 0.6m3/min | 0.8 Mps 0.8m3/min |
| Main power/voltage | 2.2KW/220V 50Hz | 2.5KW/ 220V 50Hz | 2.2KW/ 200V 50Hz | 4.5 KW/ 220V 50 Hz |
| Dimension | L1458*W920* H1392mm | L1500*W1140* H1540mm | L1250mm*W1600mm* H1700mm | (L)1360×(W)1630× (H)1900 mm |
| weight | 480kg | 680kg | 800kg | 900 kg |
As a packing machine manufacturer and supplier in China, we can also manufacture grinding machine, drying equipment and many other types of food processing equipment. We welcome you to contact us for more information. We are confident that we can provide you the food equipment you are looking for.
