Hongyan Tampa Euro III 4×2 Tractor Truck

Hongyan Tampa Euro III 4×2 Tractor Truck

Heavy Duty Truck Manufacturer in China

Offer tractor unit, dump truck, cargo truck, concrete mixer truck, bulk cement truck, tanker truck, etc.

This product has been discontinued and removed from our shelves.

Our 4×2 tractor trucks include Hongyan XinDaKang Euro II tractor truck and Hongyan Tampa Euro III tractor truck. The former adopts specially-designed Hongyan XinDaKang cab and the latter use Hongyan Tampa cab. They all use Φ430mm single plate large diaphragm spring clutch and Fuller 9-speed transmission.

Technical Parameters
Hongyan Tampa Euro III 4×2 Tractor Truck
ModelCQ4184STWG351
Driving type4×2
Total mass kg42000
Tractor curb weight kg6870
Saddle carrying capacity kg11000
Total mass of the trailer kg35000
Wheelbase mm3500
Outline dimensions mmLength6071
Width2500
Height3344,3513,2980
Max. speed km/h90
Max. gradeability %28
Fuel consumption under certain conditions L/100km38
Saddle joint face ground clearance mmIdle load/full load: 11.00 tire 50#saddle:1341/1265;11.00 tire 90#saddle:1391/1315
Saddle front/rear turning radius mm1540-2050/1800
Distance between saddle and balance shaft mm560
Traction pin diameter mm50.8 or 88.9
Engine modelWP10.336
Engine power kw(Ps)247(336)
Max. torque/speed (N.m/(r/min))1250/1200~1600
ClutchΦ430mm single plate large diaphragm spring clutch
TransmissionFuller 9
CabHongyan Tampa cab
Steering gearGerman ZF CQ8111D rotary valve steering gear
Driving axleFull floating, double reduction with differential, Steyr cast steel driving axle
Tire11.00-20,12.00-20,11.00R20,12.00R20
Emission standardEuro III

SAIC HONGYAN Automotive Co.,Ltd is a tractor truck manufacturer based in China. We specialize in producing various kinds of heavy duty trucks, like dump trucks and cargo trucks. Knowing the importance of product quality, we use advanced IVECO prototype technology, employ highly experienced engineers, and implement strict quality control system. Hence, the quality of our products like tractor unit, dump trucks, cargo trucks is highly guaranteed. As our heavy trucks are both aesthetic and practical, they are widely accepted by customers worldwide.

We welcome you to contact us for more information!
