Description of Automatic Ice Storage
Our automatic ice storage is applied for automatic ice supply and storage for situations where considerable ice is temporary in need. It could automatically level the ice produced by ice maker in the container until the container is full. When there is less ice left in the container, it could restart the ice maker automatically. Snowkey automatic ice storage falls into two types: containerized and combined type. Movable and easy to install, they are designed with a storing capacity ranging from 18 tons to 200 tons. The containerized ice storage could be installed inside a 40 feet container. These ice storages are easy to be transported by truck, railway and ship. Therefore, it is especially applicable at remote area or on occasions where ice making equipment is required to be moved from one site to another frequently.
All the components of Snowkey automatic ice storage are carefully selected to ensure continuous operation, long serving time and minimized maintenance.

Features of Automatic Ice Storage
1. Double-layer design, enabling air circling even when the container is full
2. A cooling device is also equipped to keep the ice dry and crispy (at the temperature of -8℃)
3. Movable and easy to install
4. Fully automatic

Parameters:

Model	Ice storage capacity (Tons)	Type	Length (mm)	Width (mm)	Height (mm)	Net weight (Tons)
AIS8	7	Containerized	6058	2438	2896	7.5
AIS18	15	Containerized	12192	2438	2591	12.3
AIS23	18	Containerized	12192	2438	2896	13.6
AIS35	35	Combined	12192	3530	3715	20.4
AIS40	40	Combined	12192	4130	3715	22.4
AIS50	50	Combined	12192	4130	4195	23.3
AIS50S	50	Combined	12192	5191	3565	25.3
AIS60	60	Combined	12192	5191	3965	26.1
AIS65	65	Combined	12192	5191	4195	26.6
AIS80	80	Combined	12192	5191	4865	28.3
AIS70	70	Combined	15000	5191	4195	38.1
AIS100	100	Combined	15000	5191	4965	41.5
AIS120	120	Combined	15100	5291	6005	53.5
AIS150	150	Combined	15100	5291	6965	56.7
