YCZX45 Case Packer, Case Packing Machine
Application
The YCZX45 wrap around case packer's production capacity is 40 cases/min, which is suitable for carton packaging on bottle (can) production lines for beer, other beverages, bottled water, medicine, food, and more. With this packaging method, users can save about 1/5 of the cost of packaging materials when compared to traditional packaging methods.
| Equipment model | YCZX45 |
| Machine dimension | L12380mm *W1960mm *H2300mm |
| Formed carton dimension | 520 < L+W+H < 1000 |
| Production capacity | 40 cases/min |
| Working voltage/power | 380V, 50Hz/16KW three phase |
| Hot melt adhesive solidify time | 1.5~2S |
| Working air pressure | 0.6~0.8Mpa |
| Machine weight | 7000kg |
| Bottle height | 110~230mm |
| Bottle diameter | ф50~180mm |
- Using internationally known hot melt adhesive equipment, operation is easy and the equipment is durable.
- Advanced technology, including reasonable mechanical structure of linear bottle and board feeding, reliable pneumatic device and advanced electric-control technology.
