YCZX40 Case Packer, Case Packing Machine
Application
The YCZX40 wrap around case packer's production capacity is 35 cases/min, which is suitable for carton packaging on bottle (can) production lines for beer, other beverages, bottled water, medicine, food, and more. With this packaging method, users can save about 1/5 of the cost of packaging materials when compared to traditional packaging methods.
| Model | YCZX40 |
| Machine Dimension | L10810mm*W4900mm*H2620mm |
| Formed Carton Dimension | Max:480*320*340mm Min: 264*198*116mm |
| Capacity | 35 cartons/min |
| Power Supply Capacity | 3 Phase 380V 50Hz/13KW |
| Hot-melt Adhesive Solidify Time | 1.5~2S |
| Working Air Pressure | 0.6~0.8Mpa |
| Machine Weight | 7000kg |
| Bottle Height | 116~340mm |
| Bottle Diameter | Φ50~180mm |
- Improves various wrapper packaging control functions, detect errors and display messages automatically for maintenance and guidance with human-computer interaction interface.
- Uses a well-known electrical control system and servo control system with stable operation and high efficiency.
- Reasonable cardboard-feeding structure: Cardboard is controlled by the servo control system in batches from tilted to flat, ensuring a stable supply.
- Linear structure, wide-face feeding mode, carton gluing located on the left and right sides and long holding time to make the carton stronger.
- Using famous hot melt adhesive equipment, operation is easy, and the equipment is durable. Products are packaged with a neat, beautiful appearance, and are easy to store and transport. easy operation and durability.
