SA-YZ30A Hydraulic Tensioner
Item Number: 07155
Our SA-YZ30A Hydraulic Tensioner is an ideal product for releasing a variety of electric conductors and ground. Also, it is applicable for the tension stringing operation of both optical fiber composite overhead ground wire (OPGW) and all-dielectric self-supporting optic fiber cable (ADSS).
The bullwheel of our SA-YZ30A Hydraulic Tensioner adopts the wear resistant MC nylon lining segments. In addition, the infinitely variable pay-off tension can make the constant tension stringing come true. In case of hydraulic failure, the spring applied hydraulically released multi-plate brake can work automatically to ensure the safe operation.
Main Specifications
| Model | SA-YZ30 Hydraulic Tensioner |
| Maximum Tension (kN) | 30 |
| Continuous Tension (kN) | 25 |
| Maximum Speed (km/h) | 5 |
| Bullwheel Bottom of Groove Diameter (mm) | Φ1200 |
| Number of Grooves | 5 |
| Maximum Pullback (kN) | 20 |
| Maximum Diameter of Suitable Conductor (mm) | Φ32 |
| Engine Power / Speed (kW/rpm) | 11/2200 |
| Dimensions (mm) | 3560 × 1600 × 2220 |
| Weight (kg) | 1700 |
Main Components
| Engine | Chinese top-brand water-cooled diesel engine |
| Main Pump/Motor | Chinese famous-brand pump and motor |
| Reducer | RR (Italian) |
| Radiator | AKG |
| Hydraulic Instrument | WIKA |
| Option | Imported engine (Product Model: SA-YZ30B, Item number: 07156) |
