YCZX35 Case Packer, Case Packing Machine
Application
The YCZX35 case packer, case packing machine features a production capacity of 25-30 cases/min, and is suitable for carton packaging for bottle (can) production lines such as beer, beverages, bottled water, medicine, food, and more. Cardboard wrapping method saves about 1/5 of the cost of package materials compared to traditional packaging methods.
| Model | YCZX35 |
| Machine Dimension | L5100mm*W2500mm*H1800mm |
| Molding Carton Dimension | 550 < L+W+H < 1000 |
| Capacity | 25-30 cartons/min |
| Power Supply Capacity | 380V, 50Hz/7KW three phase |
| Hot-melt Adhesive Solidify Time | 1.5 ~ 2S |
| Working Air Pressure | 0.6 ~ 0.8Mpa |
| Machine Weight | 2500kg |
| Air Consumption | 600 NL/min |
- A combination of the centralized system and human-machine interface improves the various control functions for wrapper packaging. Users can directly, enter, modify and store the parameters for multiple package specifications.
- Using flat cardboard one-time wrapping and unique forming carton technology, the carton is more firm with a pleasing exterior, and the operator's labor intensity requirements have been lowered.
- This equipment uses a famous hot melt adhesive equipment, and features easy operation and durability. Packaged products have a neat, beautiful appearance that are convenient for storage and transportation.
- With a small machine body, the equipment is safe and saves space.
