Kusing Diesel Generator, K30600
Technical Parameters
| Model | K30600 | ||
| Phase | 3 Phase | ||
| Power Factor | 0.8cosØ | ||
| Frequency | 50HZ | 60HZ | |
| Speed | RPM | 1500 | 1800 |
| Max. Power | KVA | 82.5 | 90.8 |
| KW | 66.0 | 72.6 | |
| Rated Power | KVA | 75.0 | 82.5 |
| KW | 60.0 | 66.0 | |
| Rated Voltage | V | 400 | 400 |
| Rated Current | A | 108 | 119 |
| Fuel Consumption | G/KW.H | ≤230 | |
| Generator Controller | Auto Multi-function | ||
| Engine Model. | LR4B3Z-D92F | ||
| Alternator | TCU228E | ||
| Clinder No. | 6 | ||
| Starting System | Electric Start | ||
| Cooling Method | Water-cooling | ||
| Protection Grade | IP21-IP23 | ||
| Insulation Class | H | ||
| Size (MM) | Silent Type | 2600*1100*1450 | |
| Open Type | 1960*800*1100 | ||
| Optional | ATS (auto transfer switch) | ||
