EMT01 2 Flute Carbide Router Bit

EMT01 2 Flute Carbide Router Bit
EMT01 2 Flute Carbide Router Bit
EMT01 2 Flute Carbide Router Bit
EMT01 2 Flute Carbide Router Bit
: http://metalworking-tool.com/2-1-emt01-carbide-hrc45-router-bits-2-flutes.html
  • Designed for low hardness materials (under HRc45) such as alloy steel, inconel, tools steel, carbon steel, prehardened steel, stainless steel, titanium alloy
  • Provides excellent surface finishes on the workpieces
  • Center & slotting cutting
Application
Product Specifications
Coating AITiN /TiALN /TiSiN HRC HRC35/45
Helix Angle 35°/36°/37° Shank Cylindrical H6
Material IMC™ Carbide Rod Tolerance on Cutting Diameter 0-0.030
Carbide, HRC45 Router bits, 2 Flutes（UNT-EMT01）- Universal and Economical Style
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Shank Dia.
D2 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMT0100240 0.2 4 0.4 50 2
EMT010034 0.3 4 0.6 50 2
EMT0100440 0.4 4 0.8 50 2
EMT010054 0.5 4 1.0 50 2
EMT010064 0.6 4 1.2 50 2
EMT010074 0.7 4 1.4 50 2
EMT010084 0.8 4 1.6 50 2
EMT010094 0.9 4 1.8 50 2
EMT010104 1.0 4 3 50 2
EMT010124 1.2 4 4 50 2
EMT010154 1.5 4 4 50 2
EMT010184 1.8 4 6 50 2
EMT010204 2.0 4 6 50 2
EMT010254 2.5 4 6 50 2
EMT010284 2.8 4 8 50 2
EMT010304 3.0 4 8 50 2
EMT010354 3.5 4 10 50 2
EMT010404 4.0 4 11 50 2
EMT010106 1.0 6 3 50 2
EMT010156 1.5 6 4 50 2
EMT010206 2.0 6 6 50 2
EMT010256 2.5 6 6 50 2
EMT010306 3.0 6 8 50 2
EMT010356 3.5 6 10 50 2
EMT010406 4.0 6 11 50 2
EMT010450 4.5 6 13 50 2
EMT010500 5.0 6 13 50 2
EMT010550 5.5 6 16 50 2
EMT010600 6.0 6 16 50 2
EMT010650 6.5 8 20 60 2
EMT010700 7.0 8 20 60 2
EMT010750 7.5 8 20 60 2
EMT010800 8.0 8 20 60 2
EMT010850 8.5 10 25 75 2
EMT010900 9.0 10 25 75 2
EMT010950 9.5 10 25 75 2
EMT011000 10.0 10 25 75 2
EMT011050 10.5 12 30 75 2
EMT011100 11.0 12 30 75 2
EMT011200 12.0 12 30 75 2
EMT011600 16.0 16 40 100 2
EMT011800 18.0 18 40 100 2
EMT012000 20.0 20 40 100 2

• Router bits with non-standard sizes or specifications not listed above can be customized according to customer needs.
