1000-1200W Drive Motor, PMDC Brushless Motor TF133BH
Your Motion
Application: E-tricycle
Technical Specifications
| Rated Power (W) | 1000 | 1200 |
| Max. Power (W) | 2000 | 2500 |
| Rated Voltage(V) | 48/60/72 | 48/60/72 |
| No-load Current(A) | ≤5.0 | ≤6.0 |
| No-load Revolution (RPM) | 3600 | 3900 |
| Rated Torque (N•m) | 2.8 | 3.2 |
| Max. Torque (N•m) | 16.0 | 20.0 |
| Rated Revolution (RPM) | 3300 | 3600 |
| Rated Current(A) | 23 | 26 |
| Rated Efficiency (%) | ≥75 | ≥75 |
| Working Cycle (min.) | S1 | S1 |
| Insulation Class | F | F |
| Protection Level | IP33 | IP33 |
| Gear Ratio A | 8.3/10/12.3/19 | 8.3/10/12.3/19 |
| Gear Ratio B | 11-18/11-23 | 11-18/11-23 |
| Length (L/mm) | 214 | 214 |
Note: we can customize any BLDC drive motors according to your application requirements and working conditions.
