The edge folding machine is specially designed for the production of expansion file inner pages. It uses slitting sheet materials and then completes rolling creasing, die cutting, pneumatic flanging, heat pressing and shaping and ultrasonic sealing until the production of various expansion file inner pages is complete. Processes from roll material charging to finished product output are all continuously completed.

Process display
  • Raw material
  • Trimming
  • Rolling creasing
  • Index cutting
  • Folding
  • Ultrasonic and heat pressing sealing
  • Cutting
  • Finished products
  • Finished products
    Mechanical properties
    • The edge folding machine carries out PP roll barrel running, creasing, label stamping and sealing welding.
    • It can be equipped with various die devices to ensure the same inner page size.
    • It uses ultrasonic sealing for inner pages.
    Technical parameters
    Model SYS-503EF-SA
    Power 5KW
    Required Air Pressure 5bar
    Effective Working Size A4,FC and CH
    Final product Whole set inner pages for expansion file
    Main Motor 3HP 6P with inverter
    Machine dimension (L×W×H) 7000×1200×1250mm
    Net weight 1900KG
    Gross Weight 2100KG
