Features
  • The mirror mount has good stability with high strength spring reset device installed at many places.
  • The mirror mount has good stability with high strength spring reset device installed at many places. It can be used for reflecting light, splitting light and mixing colors. It is mostly applied in laser processing and automatic measuring.
  • The diameter of the linear actuator is the same with the screw thread of the mirror mounts, so it can be replaced according to the needs of the customers.
Specification
Model WN04EM(38.1-50.8)
Tilt angle about two axes ±5°
Function θx,θy two-dimensional pitching adjustment
Optics diameter 38.1-50.8mm
Drive method M6X0.25 two-axis fine threaded screw drive
Drive motor DC motor
Material Aluminum alloy
Surface treatment Black anodizing
