Double Decker Needle Loom

Double Decker Needle Loom
Double Decker Needle Loom
Double Decker Needle Loom
Double Decker Needle Loom
Double Decker Needle Loom
  • TXF 10/25
  • TXF6/80

With the webbing width range of 1mm to 25mm, the double decker loom is known for its exceptionally high productivity. It carries out the production of two layer webbing, with a maximum of 20 weaving heads.

Parameters
Model Heads / lines Max. width(mm) Heald frame Pick pepeat Weft density(cm) Machine rotation speed(r/min)
D10/25 10-20 25 12(16) 8-48 3.5-36.7 1000-1200
Optional devices
  • Three roller automatic rubber feeding device
  • Double roller automatic rubber feeding device
  • Double take off wheel device
  • Double take off roller device
  • Automatic weft feeding device
  • Belt weft feeding device
  • Double weft double latch needle device
  • Double hook and double latch needle device
  • Frequency converter
  • Counter
  • Front / rear automatic take-up machine
  • Rear creel number
Features
  • The compact and advanced machine structure ensures the needle loom features a small footprint.
  • Main parts are produced using CNC equipment with a process precision of 0.005mm, ensuring machine durability and reducing the depreciation rate, offering more benefits to the user.
  • Lubrication is carried out using an automatic-circulation lubrication system. A broken yarn automatic stop function provides effective control over fabrics used while saving both time and labor.
  • The yarn feeding device utilizes a belt transmission with a gear for flexible speed shifting. This ensures weft yarn feeding stability and ensures the machine is suitable for the production of a variety of webbing types.
