Dockless Bike Sharing System
Request a Quote
The smart Bluetooth sensor rod features an innovative design, looks like a pole for indicator, which is easy to notice. The Bluetooth device and battery are built inside the rod. When a bike is inside the Bluetooth sensory area, the lock inside the bike will be paired with Bluetooth device inside the Bluetooth sensor rod, bike locking function is activated, and the bike is able to be returned.
Solar panel can be installed to power the Bluetooth sensor rod according to customer’s need, which makes the system eco-friendlier, and makes the battery more durable.
Main parameters- Voltage: 36V
- Current: 12.8A
- Response time: ≤5 seconds
- Tracking and data communicating function;
- Mobile phone unlocking function;
- Set electronic fence with app, to appoint certain areas for parking;
- Automatically stop bike renting by locking;
- With built-in sensor, buzzer alarm will be activated when the bike is abnormally locked/unlocked, damaged for moved;
- Constant switch ≧ 15,000 times;
- Low voltage alarm;
- Power consumption ≦ 30UA;
- Unlock delay ≦ 5s;
- Working temperature: -25℃-+75℃;
- Working humidity: 0%-90%RH, no condensation.
- Water, shock, rust, and damage resistant;
- Unified installation with bikes.
Optimal Plans (Reference Only)
① Small-Scale Plan
- Suitable population/city size: 80,000/4km2, suitable for downtown area with tiny roads.
- Electronic fence site number: 60
- Bluetooth sensor rod number: 60
- Bike number: 500
- Recommended bike type: bike with Bluetooth lock
② Medium-Scale Plan
- Suitable population/city size: 100,000-140,000/10km2, suitable for downtown area with tiny roads.
- Electronic fence site number: 180
- Bluetooth sensor rod number: 180
- Bike number: 1000
- Recommended bike type: bike with Bluetooth lock
③ Large-Scale Plan
- Suitable population/city size: 500,000/15km2, suitable for downtown area with tiny roads and dense population.
- Electronic fence site number: 2000-3000
- Bluetooth sensor rod number: 2000-3000
- Bike number: 15000
- Recommended bike type: bike with Bluetooth lock
