RF Press, HF Board Joining Machine Edge Gluer of Heavy Duty Version Manufacturer

RF Press, HF Board Joining Machine Edge Gluer of Heavy Duty Version

: http://hfwoodmachinery.com/2-3-heavy-duty-hf-edge-gluer/187657/index.html

HF Drying In Seconds

The heavy duty RF press supplied by Jiyuan can be customized according to different specifications of customer wood boards, including length, width, and thickness while still providing a stable performance and a long service life. As a kind of commonly used continuous edge gluer, the radio frequency press also suits a variety of purposes including wood board gluing, pressing and jointing.

Features of the RF Press

Radio frequency heating technology used in our wood board joining machines ensures selective heating, meaning it only heats the glue line, allowing the glue to dry uniformly from within.
Radio frequency kills bacteria and borers in the wood, ensuring it is of the highest possible quality.
This radio frequency edge gluer is designed for heavy duty woodworking, and is designed with a PLC control system that features a user friendly touch screen. One touch on the machine can control the entire process.
This particular woodworking machinery can be customized accordingly.

Technical Parameters of Heavy Duty RF Press

Model	GJB-PI-59A-JY	GJB-PV-79LA-JY	GJB-PIX-65A-JY	GJB-PL-167A-JY
Control type	PLC automatically control, fault self-checking, showing and alarm system
HF power	30KW-50KW, 6.78MHz
Worktable size	3000×1250mm	3000×1250mm	4000×1250mm	6200×1250mm
Thickness	Thickness ≤ 100mm	Thickness ≤ 150mm	Thickness ≤ 100mm	Thickness ≤ 100mm
Total pressure	59T	79T	65T	167T
Functions	1) Finger joint board making 2) Door pocket sealing 3) Batten sealing 4) L-type door parts joining

Application

4000mm long
4500mm long
5200mm long
