PDG10 Series Smart Effi Pump Drive

PDG10 Series Smart Effi Pump Drive
Request a Quote

    PDG10 series multi-purpose smart pump drive is typically designed to control the speed of water pump, which is independently developed by SAJ. It is commonly installed inside the electric control cabinet, can be connected to pressure sensor, remote pressure gauge, pressure switch and other various sensors. This smart pump drive is featured by easy operation, high reliability, low noise level and economic performance. Each pump can be outfitted with one frequency conversion pump drive, thus achieving smart online operation of multiple pumps.

    Power range
    • 220V single-phase input: 0.75-2.2kW
    • 380V three-phase input: 0.75-400kW
    Features
    • Two-way communication, strong expansibility
      Standard RS485 and CAN communication interfaces, implementing online operation and monitoring
      Standard two-way relay, one-drive-two with alternative operation
      Standard two-way analog input, current and voltage can be switched randomly
    • Online operation of multiple pumps, can be adjusted by anyone
      Easy connection of multiple pumps, up to 6 units
      One-key pressure setting, easy to adjust macro parameters
    • Exclusive water supply function
      Single-point/multi-point pressure testing, more accurate and energy saving
      Targeted control: sleep mode, leakage, automatic reset operation
      Special protection: dry run, antifreeze, high and low pressure alarm
    • Broad applicability
      Versatile design
      Wide power range 0.75-400kW
      High stability and reliability
      Open type panel control function, suitable for both fan and pump
    • Wide range of applications
      Non-negative pressure water supply system
      Secondary pressure-boosting water supply system
      Water treatment, circulating water system
      Air conditioning cold and hot water system
      Small water supply system for villa
    Specifications
    Voltage Power Rated Rated output current (A) Series 2:220V S:single-phase Adaptive
    grade input current (A) No. 4:380V motor
    KW HP T:three-phase power
    Single-phase 220V 0.75 1 8.2 4.5 PDG10 2 S R75
    1.5 2 14 7 PDG10 2 S 1R5
    2.2 3 23 9.6 PDG10 2 S 2R2
    Three-phase 380V 0.75 1 3.4 2.1 PDG10 4 T R75
    1.5 2 5 3.8 PDG10 4 T 1R5
    2.2 3 5.8 5.1 PDG10 4 T 2R2
    4 5.5 10.5 9 PDG10 4 T 4
    5.5 7.5 14.6 13 PDG10 4 T 5R5
    7.5 10.2 20.5 17 PDG10 4 T 7R5
    11 15 26 25 PDG10 4 T 011
    15 20 35 32 PDG10 4 T 015
    18.5 25 38.5 37 PDG10 4 T 18R5
    22 30 46.5 45 PDG10 4 T 022
    30 40 62 60 PDG10 4 T 030
    37 50 76 75 PDG10 4 T 037
    45 60 92 91 PDG10 4 T 045
    55 70 113 112 PDG10 4 T 055
    75 100 157 150 PDG10 4 T 075
    93 125 180 170 PDG10 4 T 093
    110 150 214 210 PDG10 4 T 110
    132 180 256 253 PDG10 4 T 132
    160 220 307 304 PDG10 4 T 160
    185 255 345 340 PDG10 4 T 185
    200 275 385 377 PDG10 4 T 200
    220 300 430 426 PDG10 4 T 220
    250 340 468 465 PDG10 4 T 250
    280 380 525 520 PDG10 4 T 280
    315 430 590 585 PDG10 4 T 315
    355 480 665 650 PDG10 4 T 355/400
    400 545 785 725 PDG10 4 T 400
    Dimensions
    AC Drive Model Size (mm) Installation
    dimension (mm)
    Opening size (mm)
    H W D D1 H1 W1 d
    PDG10-2SR75B-E 187 88 138 130 177 73 5
    PDG10-2S1R5B-E
    PDG10-2S2R2B-E
    PDG10-4T004B-E 207 100 147 139 197 85 5
    PDG10-4T5R5B-E 247 130 167 159 237 113 5
    PDG10-4T7R5B-E
    PDG10-2T5R5B-E 348 182 211 196 331 156 6
    PDG10-2T7R5B-E
    PDG10-4T011B-E
    PDG10-4T015B-E
    PDG10-4T18R5B-E 373 220 205 190 356 156 6
    PDG10-4T030B-E 435 256 222 208 419 170 6
    PDG10-4T037B-E
    PDG10-4T045B-E 543 310 280 265 523 245 10
    PDG10-4T055B-E
    PDG10-4T075B-E 580 358 328 314 560 270 10
    PDG10-4T093B-E
    PDG10-4T110B-E
    AC Drive Model Size (mm) Installation
    dimension (mm)
    Opening size (mm)
    H H2 W D D1 H1 W1 d
    PDG10-4T132B-E 1199 350 502 355 342 842 320 10
    PDG10-4T160B-E
    PDG10-4T185B-E
    PDG10-4T200B-E 1570 426 600 408 398 1147 400 12
    PDG10-4T220B-E
    PDG10-4T250B-E
    PDG10-4T280B-E
    PDG10-4T315B-E 1696 426 800 408 398 1266 520 12
    PDG10-4T355B-E
    PDG10-4T400B-E
