Stone Crushing Sand Maker Manufacturer

Stone Crushing Sand Maker

: http://janeoocn.com/9c-sand-separator.html

Application
The stone crushing sand maker from Vostosun operates to provide users with high quality stone aggregate for building, highway or railway construction, public works, large water conservancy facilities, concrete batching plant and other fields. The stone crushing sand maker is auxiliary equipment for artificial sand making and stone shaping applications.

More Details

Parameters

Model		HXVSI-7611	HXVSI-8518	HXVSI-9526	HXVSI-1140
central feeding with cascade feeding (t/h)		120-180	200-260	300-380	450-520
central feeding (t/h)		60-90	100-130	150-190	225-260
Max feeding size of soft material (mm)		35	40	45	50
Max feeding size of hard material (mm)		30	35	40	45
Rotational speed (r/min)		1700-1890	1520-1690	1360-1510	1180-1310
Double motor power (kW)		4P 110	4P 180	4P 264	4P 400
Overall dimension (L×W×H) (mm)		3700×2150×2100	4140×2280×2425	4560×2447×2778	5000×2700×3300
Total weight (t)		11.8	14.5	17.8	25.6
Power supply		380V 50HZ
Lubrication station	Double pump motor power	2×0.31kW
	Overall dimension (L×W×H) (mm)	820×520×1270
	Tank heater power	2 kW

Features

High crushing rate: stone on metal crushing cavity, higher crushing efficiency.
Large throughput: larger throughput with deep cavity rotors.
Easy to maintain: easy to inspect, repair and maintain with an integrated hydraulic opening and closing device.
Excellent product shape: cube product, fine grain shape, reasonable grading and adjustable fineness.
